Cavo ethernet CAT6 UTP PVC 8 fili 24AWG Rame 305metri

Descrizione

Data Sheet Matassa 305m  Guaina LSZH         Content of Data Sheet Product model CAB-6-BE Product specification HSYV-6 4×2×0.52 Test Standard ISO/IEC11801ãTIA-568-C.2ã YD/T1019 Conductor Material Solid-Bare Copper AWG 24 Nom.OD(mm) 0.52±0.03 mm DC resistance 95 /km Insulation Material HDPE Thickness 0.2±0.02 mm Diameter 0.93±0.05 mm Color Blue/White- Blue Green/White-Green Orange/White-Orange Brown/White-Brown Pitch Offset pitch 20 mm Cable pitch 120 mm Sheath Material PVC(complies RoHS/REACH) External OD 5.8±0.3 mm  Color Orange Tensile strength >13.5 MPa Thickness 0.6±0.05 mm Surface Printing Letter height 3.0±0.3 mm Color Black Print error & Space 1±0.005 m Case number Yes Packing Packing Carton Once packing dimension 420mm*205mm*420mm Twice packing dimension 450mm*440mm*445mm Twice packing quantity 2 cases Packing length 305±1m Rip-cord Yes Crossing backbone Yes Ambient temperature -20âï½60â
